| No | Item | Description |
|---|---|---|
| 1 | Process Type | Thermal Time Divided ALD |
| 2 | Gases Flow Type | Lateral Type(Traveling Wave) |
| 3 | Available Thin Film | Metal oxide thin film based DI or O3 Metal nitride thin film based NH3 |
| 4 | Equipment size (W x L x H) | 780mm x 780mm x 780mm (Standard) |
| 5 | Base Pressure | ＜ 5 E-3 Torr |
| 6 | Substrate Size | 8” (ø200) Substrate |
| 7 | Temperature | Max. 430 ℃ ± 1% (On Set Temperature) |
| 8 | Number of MFC | Ar 5EA Each of 500 sccm - Precursor delivery 3EA, Precursor dilution 1EA , Reactant dilution 1EA External Gas Reactant Max 3EA 500 sccm (TBD) |
| 9 | Number of Canister | Max 3EA - Concept #1 : 2 Precursor canister and 1 DI water(Reatant) - Concept #2 : 3 Precursor canister |
| 10 | Control System | Provided laptop computer & Windows 10 based, advanced and basic GUIs with Import/export of Excel compatible recipes and data |
| 11 | Gases | All gases regulated more than 4~6 Bar |
| 12 | Air | CDA, More Than 4~6 Bar |
| 13 | PCW | PCW, More Than 10LPM (필요 시) |
| 14 | Power | System : 3Phase , 220V, 60Hz, 30A 이상 |
| 15 | Vacuum | Recommended Oil rotary pump (>1,000 LPM) |
| 16 | O3 Generator (Option) | Max 220g/m2 (O2 Gas 1.0LPM) |
